Make Space
For meetings in huddle rooms for 2 to 8 people, UC S07 features exceptional integrated capabilities in a compact USB camera bar.
2 people | 5 people | 8 people
All-in-one
Perfect for a BYOD (Bring Your Own Device) environment, this plug and play camera bar features an integrated camera, microphone, and speaker.
Easy set up
All you need is two cables—one for the power supply (PoE) and a Type-C USB cable.
Hands-free activation
Thanks to the PIR sensor and hands-free function, the device automatically turns on when movement is detected within a 3m range. It enters standby mode when no movement is detected in a 30-minute timeframe, reducing energy consumption.
Hear and be Heard, Everywhere
Tracking you wherever you are
Ensure better conversation with the 6 intelligent beam-forming microphones featuring 8m voice pickup. With speaker tracking and voice location locking, you and your colleagues can always get your point across loud and clear. AGC maintains constant and stable voice output regardless of the speaker's distance from the microphone.
Filter noise for what really matter
Keep the attention on you by filtering out distracting background noises like tapping, typing, or doors closing.
Hear clearly
Whether your meeting is a conversation between two people or a larger gathering of up to 8, you'll hear everyone clearly thanks to the studio-quality Hi-Fi speaker with 8 W+3 W output power. Plus, the tweeter and woofer design deliver an immersive sound experience to every corner of the room.
See and be Seen Always
See every detail
UHD 4K video offers crystal clear video images.
Razor-sharp focus from wide-angle to close-up
See everyone in the meeting room simultaneously using the wide-angle view or see a close-up of an individual attendee. The 5x digital focus is ideal for use in huddle rooms.
Easily auto-frame participants
Auto-Framing with intelligent face detection seamlessly tracks the active speaker to keep participants engaged.
Effcient Device Management
Manage flexibly
Device management flexibility means onsite IT administrators can manage the device through a USB cable via MAXHUB ALIGN (software), however, remote teams can also access the device via the cloud-based MAXHUB Pivot.
Device Management at Your Fingertips
Use MAXHUB ALIGN to update and optimize the status of your video meeting devices, and fine-tune camera performance to look your best on video calls. Device can be managed remotely for your hybrid meeting needs through the MAXHUB Pivot.
Performance You Can Count On
Never miss out on a crucial meeting. Phenomenal quality, backed by a 3-Year Hot Swap Warranty, gives you confidence that UC device will be ready when you are.
Product Specifications
Sensor : 1/2.3-inch 12MP Sony sensor
Resolution and Frame Rate
H.264/MJEPG
(1) 3840 x 2160 (2) 2560 x 1440 (3) 1920 x 1080
(4) 1280 x 720 (5) 1024 x 576 (6) 960 x 540
(7) 800 x 600 (8) 640 x 480 (9) 640 x 360
(10) 480 x 270 (11) 352 x 288 (12) 320 x 240
YUY2
(1) 640 x 480 (2) 640 x 360 (3) 480 x 270
(4) 352 x 288 (5) 320 x 240 (6) 320 x 180
(7) 160 x 120
Output Format : MJPG; YUY2; H.264
Adjustable Angle : ± 15° (V)
Special Features :
- Auto Framing: automatic adjustment FOV to fit in all participants
- Speaker Tracking: voice triggered people tracking 2 Zooming Pre-sets for instant setting up
Overall Power(Max.) : 10W
POE Power : Yes (IEEE 802.3af or 802.3at)
Dimension(Lx Hx D) : 462 x 76 x 93 mm (18.2 x 3.0 x 3.7 inch)
Dimension(package)(Lx Hx D) :
- 1pcs 538 x 160 x 169 mm (21.2 x 6.3 x 6.7 inch)
- 4pcs 628 x 433 x 380 mm (24.7 x 17.0 x 15.0 inch)
Maximum Sound Pressure : 80dBSPL@1m
Net Weight : 1.05Kg/37.04oz
Gross Weight :
1pcs 2.55kg/90oz
4pcs 12.00kg/423.29oz
Speaker
Microphone
Special Features :
- Noise Reduction,
- Echo Cancellation,
- Anti-Reverberation,
- Built-in AGC Algorithm
USB 3.0 Type-C :Connect USB host, upgrade system, etc.
Audio Out : Used for external audio equipment
DC 2.0 : Used for 12V power input power supply
RJ45 : Only support POE power supply
Operation Temperature : 0℃ - 40℃
Operation Humidity : 10% - 90%RH
Storage Temperature : -20℃ - 60℃
Storage Humidity : 10% - 90%RH
Altitude : Below 5000 meters
included :
1 x USB Cable (1.8m/70.9 inch),
1 x Remote Control ,
1 x Power Adapter, 1 x Wall-mounted Components, 1 x Peeping Cover
PIR Sensor
In power-on mode, it will automatically enter standby state If no moving object is detected within 3 meters within 30 minutes, minimizing energy consumption; In standby mode, it automatically starts up when detecting moving objects within 3 meters, simplifying the setup process.
